Taco Comfort Solutions
Taco Comfort Solutions, a 100 year old, third generation family-owned global company based in Cranston, RI, engineers and manufactures high efficiency indoor heating, cooling, and plumbing comfort systems.
Our expertise, products, and support save our customers energy, money, and resources while improving their indoor environmental quality.
Click here for more details.
Cooling & Plumbing
FI Series Base-Mounted End Suction Pumps
- Flow Range: 20 – 4,800 GPM
- Head Range (ft): 5 – 380′
- HP: ½ – 200
- RPM Range: 1160 – 3500
- Sizes: 1.5″ – 8″
TA Series Double Suction Horizontal Split Case Pumps
- Flow Range: 75 – 5,500 GPM
- Head Range (ft): 15′ – 390′
- Temperature: 250°F (standard);
- 300°F (optional)
- Working Pressure: 300 PSIG
- HP: 3 – 400
- Sizes: 2″ – 12″
TC Series Double Suction Vertical Split Case Pumps
- Flow Range: 100 – 390 GPM
- Head Range (ft): 24 – 1100′
- Temperature: 250°F (standard)
- Working Pressure: 175 PSIG (standard), 300 PSIG (optional)
- HP: 2 – 800
- Sizes: 3″ – 14″
SKS Series Vertical Split Case In-line Pumps
- Flow Range: .1 – 7998 GPM
- Head Range: .1′ – 282′
- Temperature: 250°F (standard), 300°F (optional)
- Working Pressure: 175 PSIG (standard), 300 PSIG (optional)
- HP: 1 ½ – 250
- Sizes: 1″ – 10″
Air/Dirt Separation
ASME rated ACT Series Tangential Air Separators
- Mesh Strainer Available
- GPM: Up to 10,000
- Connection Sizes: 2-36″
- Sizes: 12″ dia. x 26″ height – 84″ dia.. X 211″ height
- Working Pressure: 125,150 PSI Standard (250, 300PSI, Higher Pressures Optional)
- Max. Operating Temp.: 375F (Optional Higher Temperatures Available)
ASME rated AC/ACF Series In-line Air Separators
- Mesh Strainer Available
- GPM: Up to 30,500
- Connection Sizes: 2-36″
- Sizes: 12″ dia. x 22″ height – 84″ dia.. X 181″ height
- Working Pressure: 125,150, 250, 300PSI Standard (Higher pressures Optional)
- Max. Operating Temp.: 375F (Optional Higher Temperatures Available)
Automatic Air Vents
- Max. Operating Pressure: 125 – 250 PSI
- Max. Operating Temp.: 240°F
- Max. Venting Pressure: 50 – 150 PSI
- Media: Water
Expansion & Storage
ASME rated CA Series Expansion Tanks
- Capacity: 23-3962 Gallons (90-15000 Liters)
- Diameters: 20-72″
- Height: 29-282″
- Working Pressure: 125,150,175, 250, 300 (PSI) Higher Pressures Optional
Max. Operating Temp.: 240°F (Optional 280°F)
ASME rated Chilled & Hot Water Buffer Tanks
- Capacity: 50-3000 Gallon Standard
- Flange sizes: 2-12″ Standard
- Diameters: 20-84″
- Height: 50-160″
- Working Pressure: 125PSI Standard, (Optional Higher Pressures)
- Max. Operating Temp.: 375°F (Optional Higher Temperatures)
